PD605 Digital Migration Radio
Features
Small, Sleek, Light
The size is 119 X 54 X 27mm, PC & Metal frame, weight is 290g.
IP67 Compliance
IP67 rated withstanding up to 1m submersion for 30 minutes or more.
Rugged & Reliable
Compliant with MIL-STD-810 C/D/E/F/G standards.
Pseudo Trunk
This virtual trunking feature allocates a free timeslot for urgent communications. This effectively enhances frequency efficiency and allows you to communicate in a timely manner in emergency situations.
Full Band
Expanded frequency range of 400-527MHz.
Dual Mode (Analog & Digital)
Dual mode (analog & digital) operation ensures a smooth analog to digital migration.
Secure Communication
Provides basic/advanced digital encryption and Scrambler feature in analog mode.
Advanced Signaling
Supports multiple advanced analog signaling modes, including HDC1200, 2-Tone and 5-Tone, providing better integration into existing analog radio fleets.
DMRA Data Service
The data protocol is fully compliant to DMRA standard.
GPS Positioning (Factory Option)
The built-in GPS module supports GIS applications.
Man Down (Factory Option)
When a user falls down, the radio can automatically alert others.
Further Development Port
The reserved side port in PD60X allows users or any third party partner to further develop other helpful applications to extend radio functionalities.
One Touch Call/Text
Supports One Touch features that comprise of Preprogrammed Text Messages, Voice Calls and Supplementary Features.
Supplementary Features
PD60X provides radio enable/disable (only decode), remoter monitor (only decode) and Priority Interrupt.
Radio Priority-Based Interruption
Enable an administration or manager radio to interrupt calls for emergency or urgent communication.
DMO True 2-Slot
In DMO Hytera can provide 2-slot communication, which allows for 2 talk paths on 1 frequency.
|
Frequency Range |
UHF: 400-527MHz, VHF: 136-174MHz |
|
Channel Capacity |
32 |
|
Channel Spacing |
25/20/12.5KHz |
|
Zone Capacity |
3 |
|
Operating Voltage |
7.4V (rated) |
|
Battery |
1500mAh/2000mAh |
|
Battery Life (5/5/90 ) |
Analog: about 11 Hours |
|
Frequency Stability |
±0.5ppm |
|
Antenna Impedance |
50Ω |
|
Dimensions |
119 x 54 x 27mm |
|
Weight |
290g
|
